How to Fit Roof Bars and Crossbars to Your VW Transporter

Here’s a quick guide on how to install a set of roof bars and supporting cross bars on your VW T5 or VW T6. Whether you’re planning a road trip with your Transporter and need to maximize storage space, or just like the look, you’ll be able to fit a set of roof rack bars in about half an hour if you follow these steps.

Fitting roof bars and crossbars can make a real difference to how much you can use your van, allowing you to carry bulky items such as bikes, kayaks, or luggage with ease. In this guide, we'll walk you through the step-by-step process of fitting roof bars and crossbars to your vehicle, ensuring a secure and hassle-free installation.

Step 1: Get everything ready

Before you begin, make sure you have all the necessary parts and tools handy. This includes the roof bars and crossbars themselves, as well as the fittings which they’re supplied with. You’ll also need silicone sealant, a 5mm allen key, a screwdriver, and the instructions!

Step 2: Fitting the roof bars

Start by using a 5mm allen key to remove the blanking screws from the roof of your vehicle.
You’ll likely need to use a step ladder to get to these blanking screws, so we recommend that you have someone with you to help keep you safe and steady while you’re up there.
With the blanking screws removed, apply silicone sealant around the holes to prevent water from getting in and causing damage to your van.

Once the sealant is set, place the spacers on the roof to create a flat surface for the roof bars to sit on.
You can now attach the gaskets to the roof bars and position them on the spacers.
Secure the roof bars in place using the bolts provided, and check to make sure that you’ve got a snug fit.
Once you’re happy with how everything is fitting together, tighten the bolts evenly along the length of the roof bars.
Insert blanking bungs into the remaining holes to complete the installation.

Step 3: Fitting the crossbars

Start by assembling the cross bars by attaching the ends and rubber gaskets. Loosen the clamps underneath the crossbars so they’re ready to install. Position the crossbars in between the roof bars, and make sure they’re evenly spaced. This step is definitely easier and safer when you’ve got someone else with you! Tighten the clamps on the cross bars using a screwdriver, and make sure they’re secured firmly. Check that the crossbars are straight, and adjust if necessary.
Finish up by inserting blanking caps to cover any exposed holes and complete the installation.

Step 4: Final checks

Once all roof bars and crossbars are fitted, double-check that everything is securely tightened and properly aligned.

Test the stability of the bars by gently applying pressure, and making sure that they’re not wobbling or shifting in place. You can go back and adjust the cross bars or roof bars if you think they need it, but if you’re happy with how it all looks and feels then you’re all done!

Safety Tips

Since you’ll be working at height (even if it’s just a little bit off the ground!) we strongly suggest that you have someone else with you to help keep you safe, and to pass you tools, parts, and tea to make the whole job go faster!

Final Thoughts

Fitting a set of roof bars and crossbars to your VW Transporter is a straightforward process, and can greatly enhance its functionality.

By following this step-by-step guide, you can confidently install these accessories and prepare your van for your next adventure. For quality roof bars and crossbars, visit www.justkampers.co.uk and explore our range of products designed to meet your needs. Happy travels!
